The hydrophilic PTFE pleated filter cartridge adopts a modified hydrophilic polytetrafluoroethylene (PTFE) filter membrane, featuring extremely high porosity, high flux, and long service life. Combined with an imported flow guide layer, it prevents fiber shedding during use. Each filter cartridge undergoes 100% integrity testing before leaving the factory to ensure filtration safety. The PTFE filter membrane has excellent chemical and corrosion resistance, making it widely applicable to the clarification and sterilization filtration of strong oxidants and highly corrosive liquids in various industries.
Product Specifications | 69mm |
Length | 5”, 10”, 20”, 30”, 40” |
Filter Material | Hydrophilic PTFE Membrane |
| Flow Guide Layer | Polypropylene (PP) |
| Core/Housing/End Cap | Polypropylene (PP) |
| Seal Ring | Refer to the Order Information Selection Table |
Maximum Operating Temperature | 80℃ |
| Maximum Operating Pressure Differential | Forward 4.0 Bar @ 20℃; Forward 2.0 Bar @ 80℃ |
Adopts a hydrophilic PTFE filter membrane, enabling direct filtration without wetting, and has excellent chemical compatibility
High interception efficiency to ensure stable product quality
100% integrity testing to guarantee the integrity of the filter cartridge
Filtration of highly corrosive solutions
Filtration of strong oxidizing liquids
Filtration of high-purity electronic chemical feed solutions
Sterilization filtration of pharmaceutical chemicals
